Name: 7 pins Fischer KS IP68 Circular Waterproof sealed Connector Kse 102 Z056 140
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: KSE 102 A057 140
Price: 11.98 USD
Availability: InStock

7 pins Fischer KS IP68 Circular Waterproof sealed Connector Kse 102 Z056 140

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	ISO:9001-2015, CE ,RoHS2.0, SGS, REACH
Numer modelu:	KSE 102 A057 140

Minimalne zamówienie:	1 sztukę
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7 dni roboczych
Zasady płatności:	Western Union, L/C, D/A, D/P, T/T
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Model Shell:

Wodoodporny gniazdo kablowe

Rozmiar skorupy:

102/0f 10 mm

Nr kontaktowy:

2-9 piny

izolator:

PPS

Kolor:

Czarne, naturalne są dostępne

Wytrzymałość:

5000 razy pchanie

Podkreślić:

IP68 Circular Waterproof Connector

KSE KS Circular Waterproof Connector

KSE 102 A057 140

7 pins Fischer KS IP68 Circular Waterproof sealed Connector Kse 102 Z056 140

Fischer alterinative connector

RAYMO P/N	Lemo P/N
RM-KSE-0F-P07-KS52Z	KSE 102 Z056 140

Description

free short cable receptacle ,0F series, code 1, 7 contacts, outer shell in natural chrome-plated brass, PPS insulator, female solder contacts, collet for 4.2-5.2 mm diameter cable ,IP68
IP68 ranking, watertight under 1.5meter
Cable assemble with overmolding is an option

Features

High quality compatible circular connectors with FISCHERS
Proven Rugged,Lightweight and Compact Solution
Operational In demanding and Harsh Environment
Original Push Pull Locking System
Designed for Easy connect/Disconnect Operations
Complete customer solutions(connectors and cable assembly service)
Multiple contacts in solder & PCB are available

Shell size and contacts for option

Series	contact no.
0F/102 series	2, 3, 4, 5, 7, 9

Application

Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
Energy, like Renewable energies
Test & measurement like Data acquisition
Broadcast, like HD and SD cameras
Midcal equipments like Disposable equipment
Extreme, such as Sailboat racing

Company information

As a creative customer-oriented manufacturer located in Shenzhen, Raymo focusing on manufacturing connectors and cable assemblies to serve over 75 countries and regions since 2010.

1/ 4 pin hirose plug and D-tap male female connectors with cables assembly

Standard B series;
Waterproof/watertight K series;
Half-moon insert S series;
Standard F series;
Plastic P series.

2/ Hirose/ fischer/ / binder/ Weipu/ BNC connector.

3/ Connector with cable assembly.

KSE Shell type dimension and pictures

7 pins Fischer KS IP68 Circular Waterproof sealed Connector Kse 102 Z056 140 1

Customer feedback

7 pins Fischer KS IP68 Circular Waterproof sealed Connector Kse 102 Z056 140 2

Chooseing tips

If you have ordered this shell connector and know the original model P/N,
please tell us.We will directly offer you our correspinding one.

If you don't know much about the connector,please make choose according the following factors:
The use of enviroment,indoor or ourdoors,waterproof or not
The panel hole size, to seclect the approproate plug and socket of right dimension
the current voltage and the realization of the function, to determin the cores
seclect the appropriate clam diameter and sheath
according to the actual needs of different angles of the keys, to determin the keying
