Name: Low Voltage Circular Waterproof Connector , Waterproof Automotive Connectors
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: RM-EEG.2KC.319.ks
Price: 11.98 USD
Availability: InStock

Low Voltage Circular Waterproof Connector , Waterproof Automotive Connectors

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	CE/ROHS/SGS/ISO:9001-2015
Numer modelu:	RM-EEG.2KC.319.ks

Minimalne zamówienie:	1 sztukę
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7 dni roboczych
Zasady płatności:	T/T, Western Union, D/A, D/P, L/C, Moneygram
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Nazwa PRCT:

Wodoodporne złącze push IP68

Model:

Gniazdo do montażu patelni

Nr kontaktowy:

2-32 szpilki

Rozmiar skorupy:

0k, 1k, 2k, 3k

Kolor skorupy:

Naturalna lub czarna skorupa

Płeć:

mężczyzna, kobieta

izolator:

PPS, zajrzyj

Typ kontaktu:

Kontakty lutu/PCB/90 ° PCB

Kabel zmontowany czy nie:

Tak

Ranking IP:

IP68

Podkreślić:

waterproof wire connectors

waterproof cable connector

Prct Description

RM-K Series 0K 1K 2K 3K series PHG cable mount sokcet

Part No.:	EEG.2K.319.CLL/ RM-EEG-2KC-319KS
Prct Description:	2K size connector, EEG panel mount socket, 19pin female contact, natural chrome plated shell in brass

K series Push pull locking metal connector, cable to cable connector, free socket, inline connector

Main Futures
1	Waterproof Secure high performance push-pull Self-locking system
2	100% compatible with original Lemo K series connector
3	can plated with white or black chrome
4	2-32pin available
5	Available solder and PCB or right angle PCB contact.
6	360° EMC shield
7	Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	55/175/21	Shielding (min)	> 95dB [ at 10 MHz], > 80 dB [ at 1 GHz]
IP Rating	IP 68	Endurance(shell)	≥5000 mating cycles

Low Voltage Circular Waterproof Connector , Waterproof Automotive Connectors 0

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
0K	2	3	4	5	6	7	9
1K	2	3	4	5	6	7	8	10	12	14	16
2K	2	3	4	5	6	7	8	10	12	14	16	19
3K	3	4	6	8	9	10	12	14	14	16	18	21
3K	26	30	32

Our Company

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Our Exhibition

2020.11	Electronica Munich, Germany
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

Why Choose US?

100% compatible lemo& connector
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Help you save your cost
Fast delivery: 3-15 working days
Cable assembly offer,help you save prction time

Low Voltage Circular Waterproof Connector , Waterproof Automotive Connectors 1

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
