Name: RJ45 To Lemo PHG waterproof circular connector 1B For Video Camera
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Phg.1b.308.clld62z
Price: 11.10 USD
Availability: InStock

RJ45 To Lemo PHG waterproof circular connector 1B For Video Camera

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	CE/ ISO9000:2015/ ROHS/ SGS/ REACH
Numer modelu:	Phg.1b.308.clld62z

Minimalne zamówienie:	5 sztuk/kawałki
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7WDS
Zasady płatności:	Western Union, L/C, D/A, D/P, T/T
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Model Shell:

Bezpłatny pojemnik kablowy

Typ:

Push Pull Connector

Rozmiar skorupy:

Nr kontaktowy:

8 pinów

Łączy typ:

kontakty lutownicze z PPS/Peek Izolatorem

aplikacja:

Kamery HD i SD

Podkreślić:

PHG Waterproof Circular Connector

1B Waterproof Circular Connector

RJ45 To Lemo Circular Power Connector

RJ45 connector to Lemo push pull connector PHG for audio video camera with natural color

Parts No.: RM-PHG-1BC-308-KS52Z equal to lemo PHG.1B.308.CLLD52Z

Free cable receptacle push pull circular connectors to RJ45 connector, cable length can be done according

customer real needs, connectors can be proceed with overmolding.

Description
1	100% substitute with original LEMO
2	Brass with natural chrome plated shell, contact with gold plated
3	different shell size is available from 00B,0B,1B,2B,3B,4B,5B
4	can solder with wire to save your time
5	360° EMC shield
6	Available Solder,PCB or right angle PCB contacts
7	Robust and shock resistant designs

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>96hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz]
IP Rating	IP 50	Certifications	ISO9001 CE ROHS2.0 SGS

RAYMO is a manufacturer that:

1. Manufacturing & exporting various metal & plastic circular connectors and cable assembly

2. All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDER and provide you alternative solutions of Circular Push Pull Connectors

3. Cable Assembly can be designed according customer real needs

4. All the prcts we got CE, ROHS, SGS,ISO9000 certificate

5. OEM connector and Cable assembly

6. All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-dtap, D-Sub, USB-A, USB-B, RJ45, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO.

RJ45 To Lemo PHG waterproof circular connector 1B For Video Camera 0

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Why choose us:

Free cable solutions
100% compatible lemo connector
OEM or ODM accepted
Help you save at least 50% cost, Bend relief of plug are free
Cable assembly offer
Free sample for confirmation
Fast delivery time to help you save prction time

Price, lead time, drawing, datasheet get now!
