Name: D TAP To Lemo IP50 0B Circular Push Pull Connectors
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: ECG.0B.302.CLL
Price: 11.10 USD
Availability: InStock

D TAP To Lemo IP50 0B Circular Push Pull Connectors

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	CE/ ISO9000:2015/ ROHS/ SGS/ REACH
Numer modelu:	ECG.0B.302.CLL

Minimalne zamówienie:	5 sztuk/kawałki
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7WDS
Zasady płatności:	Western Union, L/C, D/A, D/P, T/T
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Model Shell:

Panelu Gniazdo EKG Typ EKG

Typ:

Push Pull Connector

Rozmiar skorupy:

Nr kontaktowy:

2Pin

Łączy typ:

kontakty lutownicze z PPS/Peek Izolatorem

aplikacja:

Czerwony aparat

Podkreślić:

IP50 Circular Push Pull Connectors

0B Circular Push Pull Connectors

D TAP To Lemo Circular Connectors

D TAP to lemo push pull connector cable connector for camera device power on cable

Parts No.:RM-ECG-0BC-302-KS equal to lemo ECG.0B.302.CLL

Description
1	100% substitute with original LEMO
2	Brass with natural chrome plated shell, contact with gold plated
3	different shell size is available from 00B,0B,1B,2B,3B,4B,5B
4	can solder with wire to save your time
5	360° EMC shield
6	Available Solder,PCB or right angle PCB contacts
7	Robust and shock resistant designs

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>96hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz]
IP Rating	IP50	Certifications	ISO9001 CE ROHS2.0 SGS

D TAP To Lemo IP50 0B Circular Push Pull Connectors 0

RAYMO is a manufacturer that:

1. Manufacturing & exporting various metal & plastic circular connectors and cable assembly

2. All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDER and provide you alternative solutions of Circular Push Pull Connectors

3. Cable Assembly can be designed according customer real needs

4. All the prcts we got CE, ROHS, SGS,ISO9000 certificate

5. OEM connector and Cable assembly

6. All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-dtap, D-Sub, USB-A, USB-B, RJ45, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO.

D TAP To Lemo IP50 0B Circular Push Pull Connectors 1

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Why choose us:

Free cable solutions
100% compatible lemo connector
OEM or ODM accepted
Help you save at least 50% cost, Bend relief of plug are free
Cable assembly offer
Free sample for confirmation
Fast delivery time to help you save prction time

Price, lead time, drawing, datasheet get now!
