Name: Self Latching Half Moon Connector FLA Elbow 90 Degree Plug Rapid Insertion Reliable
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Fla.0s.250.clac32
Price: 12.30 USD
Availability: InStock

Self Latching Half Moon Connector FLA Elbow 90 Degree Plug Rapid Insertion Reliable

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	CE, REACH, ISO:9001-2015
Numer modelu:	Fla.0s.250.clac32

Minimalne zamówienie:	1 sztukę
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7 dni roboczych
Zasady płatności:	T/T, Western Union, D/A, D/P, L/C, Moneygram
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Model:

Kabel do złącza kablowego

Szereg:

Lemo Fla Elbow (90 °)

Rozmiar skorupy:

0s, 1s, 2s

Nr kontaktowy:

współosiowy, 50ohm i 75oHm jest Avaialble

aplikacja:

Audio-video

izolator:

PPS, zajrzyj

Podkreślić:

pcb contacts connector

cable elbow connector

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing mental and plastic circulor push-pull connectors and cable assemblies to serve over 75 countries and regions since 2010.Prcts can be 100% compatible with original ones(LEMO,FISCHER,HIROSE,BINDER SERIES)

RM-S series Push pull locking metal connector S-series connector with Half-moon type insulator, cable to cable connector, free socket, inline connector

Push-Pull self-latching circular half moon connector, Lemo FLA Elbow (90°) plug, cable connectors, coaxial contacts

Part No.	FLA.00.250.CLAC32
Description:	FLA 0S Series circular push pull connector,straight plug with cable collet, 50ohm contacts,outer shell in chrome-plated brass,PPS insulator, C type collet for a 3.2 mm diameter cable.

Technical Characteristics
Temperature Range	- 55° C, +200° C	Resistance to vibrations	10-2000 Hz, 15g
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C
Shock Resistance	100 g, 6 ms	Salt spray corrosion test	>96hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP 50	Endurance(shell)	≥5000 mating cycles

Main Futures
1	can be 100% compatible with original Lemo connector
2	Half-moon type Secure high performance push-pull Self-locking system
3	polarisation by stepped insert (half-moon)
4	360° screening for full EMC shielding
5	can plated with white or black chrome
6	Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach

Raymo's connectors can be used in below Application:
Communications, Automotive, Industrial Control, Audio-video, Aviation, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

RM-S series FLA Cable mount Plug picture
Self Latching Half Moon Connector FLA Elbow 90 Degree Plug Rapid Insertion Reliable 0

Why Choose US?

100% compatible with lemo, , fischer connector
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Help you save at least 50% cost
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time

Except connectors,we do cable assemble for circular connectors too.Just tell us your need, leave the rest to RAYMO!

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
