Name: Automotive Circular Push Pull Connectors , Metal Cable Connectors Black Shell
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: FGG.0B.302.KLAC52Z
Price: 11.10 USD
Availability: InStock

automotive connector FGG EGG ECG 0B 2 pin metal cable connector,Circular push pull Connector

Description FGG.0B.302.KLAC52Z

FGG Cable Mount Straight Plug, Circular Push Pull Connector
0B 5pins, male solder contacts,Shell in Black
Compatible with original one
5000 time push pull life cycle

B Series connector with the following main features

·Security of the push-pull self-latching system;

·Multicore types with 2 to 32 pins;
·Solder or PCB contacts(straight or elbow);
·High-density installation for space-saving;
·Multiple key options to avoid cross mating or similar connectors;
·360-degree screening for full EMC protection

·Mechanical properties and environmental factors:
·Endurance>5000 cycles
·Humidity.up to 95% at 60ºC
·Temperature range:-45ºC~+125ºC
·Resistance to vibration:10-20000Hz,15g
·Shock resistance:100g.6ms
·Salt spray corrosion test >48hrs
·Protection index:IP50

Shell size and contacts for option

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
RM-0B	2	3	4	5	6	7	9
RM-1B	2	3	4	5	6	7	8	10	12	14	16
RM-2B	2	3	4	5	6	7	8	10	12	14	16	19
RM-3B	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
RM-4B	7	10	24

Raymo Company information

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.

This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military

Application

Broadcast, like HD and SD cameras
Energy, like Renewable energies
Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
Midcal equipments like Disposable equipment
Test & measurement like Data acquisition
Extreme, such as Sailboat racing

RM-B Series FGG Shell type dimension and pictures

Automotive Circular Push Pull Connectors , Metal Cable Connectors Black Shell 0

Exhibition

2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair

Custom service

Common model connectors stock: for common usually models, we will stock materials, once you order, we can ship out in 3 days.
Cable assembly service: we can supply cable assembly service according to your requirements.
Technical support: Any questions or problems in your connector’s or cable’s working, our technical department will supplu professinal support to help you solve them
Cable assembly solution supply: We can make cable assembly service solution to meets you need.
Customized connector service: if our present connectors can’t suit exactly what you need, we can open new mould for you.

Our Certificate

CE
Rohs
ISO:9000-2015
REACH
SGS

FAQ

1. Are your company a professional manufacturer?
Raymo: Yes, we SGS audited manufacturer
2. What is the MOQ?
Raymo: No MOQ limited, depend on customer real needs.
3. Free sample?
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: 3-5 working days for samples, 5-7 working days for mass prction.
5.What is your payment terms?
Raymo: 100% T/T in advance when customer place an order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!

Etykietka:

Miejsce pochodzenia:	Shenzhen, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	ISO:9001-2015, CE, RoHS2.0, SGS, REACH
Numer modelu:	FGG.0B.302.KLAC52Z

Minimalne zamówienie:	1 sztukę
Cena:	negotiable
Szczegóły pakowania:	Plastikowa torba i karton
Czas dostawy:	5-7 dni roboczych
Zasady płatności:	Western Union, L/C, D/A, D/P, T/T, MoneyGram
Możliwość Supply:	5000 sztuk / tydzień

Szereg:	Raymo B okrągłe złącze pchnięcia	Numer kontaktowy:	2. 3. 4. 5. 6. 7. 9 biegunów
Rozmiar skorupy:	0b, inne powłoki są dostępne	izolator:	PPS, PEEK też jest dostępny
aplikacja:	Koleje	Cykle:	5000 czasu pchania
Podkreślić:	electronic cable connectors , cable connector plug
