Name: Wire Circular Plastic Connectors Thread Connection Small Size With OEM ODM Service
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Pag.m0.2Gl.ac39a
Price: 2.30 USD
Availability: InStock

Wire Circular Plastic Connectors Thread Connection Small Size With OEM ODM Service

Podstawowe informacje

Miejsce pochodzenia:	Shenzhen, Guangdong, Chiny
Nazwa handlowa:	RAYMO
Orzecznictwo:	RoHS, Reach, SGS, ISO:9001-2015
Numer modelu:	Pag.m0.2Gl.ac39a

Minimalne zamówienie:	1 sztukę
Cena:	negotiable
Szczegóły pakowania:	Torba PE i karton
Czas dostawy:	3-5 dni roboczych
Zasady płatności:	Western Union, T/T, Moneygram, D/P, D/A, Moneygram, L/C
Możliwość Supply:	5000 sztuk / tydzień

Skontaktuj się teraz

Typ:

Lemo Redel Push-Pull Connector

Nr kontaktowy:

2-14Pins

Płeć:

Kobieta, mężczyzna

izolator:

PPS, zajrzyj

Ranking IP:

IP50

Materiał skorupy:

PC, PSU, Peek

aplikacja:

Edan Medical Feal Monitor, Monitor EKG

Kolor skorupy:

Czerwony, szary, zielony, czarny, żółty, biały, niebieski

Podkreślić:

plastic push pull connector

raymo connectors

Medical 1P M14 Circular Plastic Connector, Lemo Redel's wire pleastic connectors PAG.M0.2GL.AC39A

Raymo plastic push pull connectors RM-P series compatible with Lemo REDEL PLASTIC CONNECTORS

PARTS No.

Raymo P/N

LEMO Redel P/N

RM-PAG-1PC-302-JS39A

PAG.M0.2GL.AC39A

Description

straight plug with cable collet and alignment key (G=0 degree),

multipoles 2 contacts to solder, blue PC outer shell, PPS insulator, collet for 3.2-3.9mm diameter cable

Plastic Circular Push Pull connector RM-p series
Series	IP	Shell Size	Contacts No. with solder & PCB type
RM-P	40	1P /Redel	2	3	4	5	6	7	8	9	10	12	14

Features
1	Light weight
2	Wide choice of colors for easy identification(Grey,Blue,Yellow,Black,Red,Green)
3	Large choice of keying to avoid cross mating(0°,40°,60°,80°,155°,170°)
4	Various contact types:solder,print and elbow print 90°

Characteristics
Temperature Range	- 40° C, +110° C
IP Rating	IP 40
Endurance(shell)	1,000 cycles
Color code	Different color nut for easy Identification

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.

This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military

Cable mount plug,RM-P series, Prcts Photo, Shell size and Dimension

Wire Circular Plastic Connectors Thread Connection Small Size With OEM ODM Service 0

Why Choose US?

100% compatible with lemo, , fischer connector
Help you save at least 50% cost
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time

Wire Circular Plastic Connectors Thread Connection Small Size With OEM ODM Service 1

Our Exhibition

2020.11	Electronica Munich, Germany
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
